330103-00-03-05-12-CN 3300 XL 8 mm Proximity Probes

Technical Data

• Brand: Bently Nevada
• Model: 330103-00-03-05-12-CN
• Range: 0.25–2.3 mm (10–90 mils)
• Output Signal: -1 to -17 Vdc
• Accuracy: ±0.5Ω (probe resistance)
• Temperature: -52°C to +260°C (operating)
• Cable: 0.5m FluidLoc, ClickLoc connector
• Thread: M10x1, 30mm case length

Installation Guide

• Max cable length: 305m (1000ft)
• Use 16–24 AWG shielded triad cable
• Recommended gap: 1.27mm (50 mils) at -9Vdc
• Avoid temperatures below -34°C to protect seal

Compatibility

Works with Bently Nevada 3300 XL Proximitor Sensors and monitors. Suitable for intrinsically safe (ia) or non-incendive (nA/ec) systems.

Certifications

• AEx/Ex ia IIC T5-T1 Ga (Zone 0)
• Class I, Div 2 Groups A-D
• IEC 68-2-3 humidity certified

Packaging & Warranty

• Includes probe, docs, protective case
• 1-year limited warranty

Application Cases

• Gas turbine vibration monitoring
• Pump shaft position detection
• Motor bearing health analysis
