A9N16201 | SCHNEIDER ELECTRIC | Acti 9 xID Residual Circuit Breaker - 25 A - 2P - 30mA Class AC Instantaneous
A9N16201 | SCHNEIDER ELECTRIC | Acti 9 xID Residual Circuit Breaker - 25 A - 2P - 30mA Class AC Instantaneous

A9N16201 | SCHNEIDER ELECTRIC | Acti 9 xID Residual Circuit Breaker - 25 A - 2P - 30mA Class AC Instantaneous

$32.28
$32.28
Please hurry! Only 1000 left in stock
Limited-Time Offers, End in: 151D 8H 23M 0S
Subtotal: $32.28

Free Shipping

Free standard shipping on orders over $60

Size Guide

Understanding Mylulusstore Sizing
A9N16201 | SCHNEIDER ELECTRIC | Acti 9 xID Residual Circuit Breaker - 25 A - 2P - 30mA Class AC Instantaneous

A9N16201 | SCHNEIDER ELECTRIC | Acti 9 xID Residual Circuit Breaker - 25 A - 2P - 30mA Class AC Instantaneous

$32.28
A9N16201 | SCHNEIDER ELECTRIC | Acti 9 xID Residual Circuit Breaker - 25 A - 2P - 30mA Class AC Instantaneous

A9N16201 | SCHNEIDER ELECTRIC | Acti 9 xID Residual Circuit Breaker - 25 A - 2P - 30mA Class AC Instantaneous

$32.28
Description
Description
x
Product name Acti9 xID
Product or component type Residual current circuit breaker (RCCB)
Device short name xID
Poles description 2P
Neutral position Left
[In] rated current 25 A
Network type AC
Earth-leakage sensitivity 30 mA
Earth-leakage protection class Type AC
Rated breaking and making capacity 500 A conforming to EN/IEC 61008-1
Contact position indicator Yes
Control type Toggle
Local signalling ON, OFF, fault trip
Mounting mode Clip-on
Mounting support DIN rail
9 mm pitches 4
Height 81 mm
Width 36 mm
Depth 75 mm
Net weight 210 g
Colour White
Mechanical durability 4000 cycles
Electrical durability 4000 cycles
Locking options description Padlocking device
