Description
Description
x
The new Matrix Audio MS-1c Streamer features both analog and digital outputs. It includes a built-in high-quality DAC, it delivers both refined detail and a warm, musical character, while also supporting external DAC expansion for greater flexibility. It is an ideal choice for entry audiophiles exploring high-quality digital sources, as well as for advanced users looking to upgrade their system or experience streaming audio.
The MS-1c features signature high-resolution digital architecture that incorporates an analog-inspired toning philosophy. Its analog stage features renowned Swedish LUNDAHL precision audio transformers for signal coupling, delivering a warm, smooth, and full-bodied sound signature. The result is a richly detailed yet fatigue-free listening experience.
The MS-1c features the flagship AKM VELVETSOUND™ DAC solution, combining the AK4191 and AK4499EX chips. It supports PCM up to 32 Bit/768kHz and DSD up to 1 Bit/24.58MHz, achieving a dynamic range of up to 125dB, ultra-high SNR, and an exceptionally low noise floor. No matter high-resolution and analog-like musicality, every micro detail of the music is reproduced with ease.
The MS-1c also features dual femtosecond clock architecture. Two custom femtosecond clocks provide references for 44.1kHz and 48kHz based sampling rates. Combined with a high-speed FPGA featuring frequency division and jitter reduction algorithms, this design significantly minimizes phase noise and improves data reconstruction accuracy—resulting in enhanced airiness and texture.
The MS-1c supports a wide range of protocols such as Roon Ready, Audirvāna, TIDAL Connect, Qobuz Connect, Spotify Connect, AirPlay 2, UPnP/DLNA, and NAA. It can build local libraries from internal SSD, USB storage or NAS, and even stream music directly from Dropbox. With rich resources and broad protocol support, the MS-1c becomes a powerful and versatile audio source. By connecting an external USB CD drive, users can enjoy CD playback and easily rip CDs into digital files. Like creating a digital copy of a precious CD, perfectly blending the high-quality audio of a CD with the flexible management of a streamer. It allows you to enjoy the unique ritual of CD playback while breaking through the limitations of the physical medium of a CD.
The MS-1c features an NVMe SSD slot on the bottom allows easy storage expansion. A specially designed ultra-low-noise independent power supply ensures a clean environment for the SSD—far superior to regular computer implementations. The internal storage is accessible over the local network, making library management simple. The device can also function as a NAS, serving music to other streamers on the network.
The MS-1c supports both wired Ethernet and Wi-Fi 6 connectivity. The gigabit Ethernet offers the most stable performance for high-resolution PCM and DSD playback. When cabling is inconvenient, Wi-Fi 6 provides a flexible and convenient alternative for high-quality streaming.
The MS-1c features a carefully engineered architecture of power with separate supplies for digital and analog circuits. A dedicated linear power supply for analog stages, combined with multiple LDO regulators, minimizes ripple and noise, ensuring a clean and stable power foundation for superior sound performance.

Specifications:



Digital Output
OPTICAL, COAXIAL, AES/EBU PCM 16-24Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz

DSD 2.82MHz,  3.07MHz(DoP)
IIS LVDS

PCM 16-32Bit /44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz

DSD 2.82MHz, 3.07MHz, 5.64MHz, 6.14MHz, 11.29MHz, 12.29MHz, 22.58MHz, 24.58MHz
USB DAC

Depends on the specifications supported by the connected USB DAC device. Not higher than PCM 32Bit/768kHz and DSD 24.58MHz.

The USB DAC port provides a maximum of 5V/1A low-noise power supply.
Analog Output
XLR

Output Impedance: 20Ω

Output Level: 4.5VRMS / 0~4.5VRMS Adjustable

SNR: >126dB A-weighting

THD+N: <0.02%@1kHz

Frequency Response: 20Hz-20kHz ±0.1 -3dB@83kHz

Crosstalk: >-130dB
RCA

Output Impedance: 20Ω

Output Level: 2.25VRMS / 0~2.25VRMS Adjustable

SNR: >123dB A-weighting

THD+N: <0.02%@1kHz

Frequency Response: 20Hz-20kHz ±0.3 -3dB@83kHz

Crosstalk: >-130dB

Network

LAN 10/100/1000 Mbps
Wi-Fi
 2.4 GHz / 5 GHz
USB

USB 3.0

The USB port provides a maximum power of 5V/1A.

The USB port works with devices which conform to the USB mass storage standard and supports FAT, FAT32, exFAT, and NTFS file formats, but is not guaranteed to be compatible with all storage devices.
MA Player
Controller app

MA Remote App

Local Playback

Format Supported: MP3, WMA, WAV, AIF, AIFC, AIFF, AAC, FLAC, OGG, APE, ALAC, M4A, DSF, DFF, CUE, ISO

PCM  16-24Bit/44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz

DSD  2.82MHz, 3.07MHz, 5.64MHz, 6.14MHz, 11.29MHz, 12.29MHz, 22.58MHz, 24.58MHz
Roon Ready

PCM  16-24 Bit /44.1 kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz, 352.8kHz, 384kHz, 705.6kHz, 768kHz

DSD  2.82MHz, 5.64MHz, 11.29MHz, 22.58MHz

Apple Music

The audio specs depend on the service provider
QQ音乐

The audio specs depend on the service provider
AirPlay 2

The audio specs depend on the service provider
DLNA/UPnP

The audio specs depend on the service provider

TIDAL Connect

The audio specs depend on the service provider

Spotify Connect

The audio specs depend on the service provider
Qobuz Connect

The audio specs depend on the service provider
vTuner

The audio specs depend on the service provider
Radio Paradise

The audio specs depend on the service provider
Trigger
Trigger in

DC 6-12V <10mA
Trigger out

DC 12V/50mA MAX
Storage Extension

 M.2 2280 2242 2230 NVMe PCIe SSD slot

SSD supporting PCIe 3.0/4.0/5.0 standards. The maximum power specification provided by the expansion slot is DC 3.3V 3A.
Power
Power Voltage

AC 100V-120V 50/60Hz or AC 220V-240V 50/60Hz, factory-fixed
Standby Power Consumption

< 5W
MAX Power Consumption

< 50W
Weight & Dimensions
Weight

 6.5kg (14.33pounds)
Dimension

Width: 430 mm (16.93 inches)

Depth: 315 mm (12.40 inches)

Height: 96 mm (3.78 inches)
