Description
xOptional accessories: Scorpion Hi-Speed Cooling Fan Alu (30mm) / Scorpion V Link II Cable / Scorpion Anti Spark DIY kit
Product Description
Airplane and Heli mode,
Stored and unstored Governor, external governor.
Data Logging, Data output port for external data logging device, such as Mikado V control / Vbar combinations. Jeti Telemetry , JLog 3 ( more compatible device will be added gradually like Futaba..etc.)
ESC setup can be set by Mikado V control Radio.
PC connectivity, Android connectivity ( OTG cable needed) , V link II Cable(optional) plus Diode adaptor(included) cable needed.
Supported HvLi battery 12S total 52V.
Size: 76.7 x 36.5 x 25.4 mm
Weight: 144 Grams.
Scorpion Tribunus ESC {Tutorial} - Connecting to PC or MAC + Downloading SProto + Firmware Updates. Produced by Kyle Dahl
Scorpion Tribunus II 12-80A - User Manual
Scorpion Tribunus Heli Program Sproto
Scorpion V Link II Cable CH340 Driver (For all ESC use)
How to update Tribunus firmware
How to DIY your own Telemetry/setup cable for the Tribunus ESCs – Vbar NEO
How to DIY your own Telemetry/setup cable for the Tribunus ESCs – Jeti
Specifications
| Max Continuous Current | 80 Amps |
| Peak Current | 100 Amps |
| Operating Voltage Range | 14-52 Volts |
| BEC Output voltage: | 5.1V to 8.1V adjustable. |
| Max Continuous BEC Output | 10 Amps @ 8.1 V |
| Peak BEC Output | 30 Amps/1s @ 8.1 V |
| On Resistance | 0.4 mOhms *2 |
| Size | 76.7 x 36.5 x 25.4 mm (3.02 x 1.44 x 1 in) |
| Weight (Without Connectors) | 144g (5.08 oz) |
| Drive frequency | 8kHz - 32kHz |
Weight including packaging
250g
