Description
xProduct Description
-
Made with rust preventive castings, assuring longer life to the product
-
Can handle hot water of up to 90℃
-
Designed to cater to the needs of multiple bathrooms at the same time
-
Premium quality pump sets
-
Rigid built cast iron castings
-
Fitted with hot water seal that can handle upto 900c
-
F-class insulation
-
Rust preventive Aluminum die-casted motor body
-
Stainless steel hardwares
-
Imported pressure tank
Product Specification
| Brand | V-Guard |
| Product Type | Centrifugal Booster Pump |
| Model | VB24-F4A |
| Power | Hp : 1 kW : 0.75 |
| Pipe Size (Suction X Delivery) | 2.5 X 2.5 cm |
| Pump Stage | 4 |
| Type Of Tank | Inline Vertical |
| Tank Capacity(L) | 24 |
| Drawdown Capacity(L) | 12 |
| Pressure Setting Range(kg/cm2) | 2.0 to 4.5 |
| Max Capacity(LPH) | 6000 |
| Approximate Suitable For | 4 Bathroom |
|
| |
| Total Head In Meters/Feet | Discharge In LPH |
| 15/50 | 4600 |
| 18/60 | 4300 |
| 21/70 | 3500 |
| 24/80 | 3200 |
| 27/90 | 3000 |
| 30/100 | 2700 |
| 33/110 | 2200 |
| 36/120 | 1600 |
| 39/120 | 1100 |
| 42/140 | 600 |
